Ford Tractor and Wartsila Crane assembly

Date Added: 09 May 2020 Contributor: Norman Davidson Year of Photo: 1976 Picture No: 4701

Photograph is courtesy of Jim Christie, Crook of Devon, a former senior mechanical engineer in the Forestry Commission.

Possibly a Chappelhall workshop image of a machine for the general use in Forestry Commission forests for timber harvesting. This machine combination was certainly made by Chieftain Forge according to a comment by David Shearer and hitched to a forwarding trailer, a Trysil, also produced by Chieftain Forge.

Note the very small winch drum in red at the bottom of the back opening plate. The rope is lead through to vertical pipe to a pulley block just below the base of the crane. An unusual arrangement and wonder how often it was used? The year allocated is uncertain.

Download Large Version (497kB)

Groups: Forestry Areas, Timber harvesters, processors, forwarders and cable cranes

Group: Forestry in Action - 1908 pictures

Pic No: 4700
Danarm Whipper saw test Pic No: 4706
Felled tree stroke processor - Timberjack RW30

3 Comments

Looking for any Chieftain Forge literature if anyone has anything, also James Jones and JHB forestry conversions Comment left on 16 November 2020 at 21:09 by Andrew

I have two Chieftain Forge tool pamphlets and a list, hand tools only no machinery
I would be willing to copy them if that is any use to you Comment left on 30 November 2020 at 23:11 by Dave Stewart

I remember the Wartsila crane, and Willie wolf of chieftain forge. Does any one recall the Belarus tractor, rough and ready but great in their day! Wartsila are developing marine engines to run on non fossil fuels, such as Ammonia. Used in Belgium in 1942 instead of Diesel which was very scarce. JCB have now got agri and construction machines, running on Hydrogen. So it’s some good news for COP 26 on the moves away from fossil fuels. Comment left on 08 November 2021 at 18:55 by Bradley borland
